Wall Mounted Bath Set with Mixer, Spout and Diverter

Some walls serve two jobs: a bath that is filled on one side and a shower on the other. This wall mounted bathtub set is built for that wall. It carries a mixer, a spout and a two way diverter, so the same control can send the water to the tub filler or across to a shower outlet without a second valve on the wall. All three pieces are AISI 316L stainless steel, the grade that suits a bathroom in regular hard use.

Key features

• Two way diverter shares one mixer between a bath spout and a shower
• Three matched pieces ordered as a set, so the finish is guaranteed consistent
• AISI 316L stainless steel, resistant to chloride and coastal air
• Wall mounted, with no floor penetration and no filler rising above the rim
• Available in five finishes including deep grey and gold PVD

Specification and installation

All three components fix to the same wall, which makes the set a single delivery on site rather than three separate hunts through a store room. Run the pipework at first fix, mount the mixer at a reachable height, and fit the spout where the flow will clear the bath. The diverter sits between them, so plan its position for reach as well as for looks before the tiling is closed up.
