Deck Mounted Bath Set With Spout And Hand Shower

This is the deck mounted version of a bath set that does the work of two fittings. Two mixers handle the hot and cold water at the rim, a spout fills the tub, and a hand shower with a support and a 1800 mm flexible hose deals with rinsing. It is the set to schedule where a bath must fill and shower from the same fittings, common in hotel and leisure bathrooms. AISI 316L stainless steel throughout, offered in five finishes.

Key features

• Spout and two mixers fill and control the bath from the deck
• Hand shower, support and 1800 mm flexible hose included in the set
• Molybdenum-bearing 316L steel, the grade used around pools and spas
• Five finishes let the set match wall and basin fittings in the same room
• One schedule line covers the whole bath, fewer items to chase on site

Specification and installation

Set out the two deck holes and the spout before the bath is fixed, since the positions are locked once the tub is in place. Mount the hand shower support on the wall above the rim, allowing the hose to hang without a tight bend. Ask the supplier to confirm the deck fitting size and the connection thread, neither of which the product record states.
