Wall Mounted Bath Filler Set With Spout

Some baths are fixed to the floor with no rim left free for a filler, and some bathrooms are designed so the pipework stays behind the tiles. A wall mounted bath filler of this type answers both: a single mixer and spout in the wall, set into a recess that discharges straight into the tub. The body is AISI 316L stainless steel and the range is available in five finishes for a scheme that mixes metalwork with stone.

Key features

• No hole is drilled in the tub, protecting the surface finish of the bath
• Set into a recess so the water falls inside the bath, not down the tiling
• 316L steel with a molybdenum content suited to hard water
• Deep grey and gold PVD sit with the two stainless steel options
• Single mixer keeps the recess narrow and the tiling pattern simple

Specification and installation

Form the recess before the wall is tiled, finishing it with the same tile or stone as the wall and sealing the junction where water collects. The outlet height must clear the maximum fill line of the chosen bath. Confirm the spout projection and the connection size with the supplier, as the record gives no dimensions. Tinta is also offered in this body.
